MSD 20AMP Magneto -w points box Pro Mag 20 Amp Mag, Wires, ( Non hemi wires )
The 20 Amp generator is a favorite in alcohol slurping engines such Sportsman Dragsters and Quick-8 racers.
Works on Blown Alcohol Engines up to 35- lbs boost
This 20 AMP Mag Generator comes with 8106 Points Box and Set of Wires.
The increased output of the 20 Amp Pro-Mag was born of racers being racers; always asking for more power.
This stemmed from drag racers that were using a 12 Amp system, but just didn’t require a 44 Amp system.
The engineers at MSD found that with a few changes to the internals of the generator it would deliver the increased current through the same Electronic Points Box, PN 8106.
There are three different generators available; a band clamp design in both CW and CCW rotation, plus a model built on a Chevy distributor base.
All three require the PN 8106 Electronic Points Box. INCLUDED
The band clamp versions are equipped with a large Ford style cap while the Chevy version uses a 4-inch cap and both are topped with heavy duty retainers.
|Spark duration||26° crankshaft rotation|
|Spark Energy||240 millijoules (at the gap)|
