Pro-Filer Sniper Ram Big Block Chevy Tunnel Ram Intake Manifold 216-9 9.8" Std Deck
* ( Distributor hole is machined for a std deck dist or mag to fit )
Height 9-3/4" without top 10-1/2" w Top
So far we have used 1792 mm 70.5" and 1760 mm 69" Belts with Success. depends on tooth count and ratio when using this with a Blower
216-9 is for 9.8" Deck 216-10 is tall deck
Use dropdown option to add , lines, nozzles, and dist block for fuel injection
The Hottest Conventional Port Tunnel Ram Available!
Series P/N: 216 (QTY & OPTIONS ADDED TO BASE PRICE AT CHECKOUT)
- RPM Range 5500-8500
- Equal Radius Inlet with Mirrored Runner Arrangement
- Machineable Plenum Depth
- Runners are Precision Cast
- Tuned Equal Length Runners assure proper air flow
- Available in 9.8 & 10.2 deck heights
Use Drop down to add nozzles, lines, dist Block and Hat top for Fuel injection OR
whatever carb top you want
The SNIPER BBC Intake Manifold Series is designed with the perfect runner to plenum volume to maximize the power and acceleration curves of your engine. The SNIPER Series features cast injection bosses, 4500 series carburetor flange, four corner water bosses and rectangular ports.
For a combination that is unbeatable, pair the SNIPER Cylinder Head with a SNIPER Manifold and watch your competition be blown away!
