    12-815-1 Holley  Black Fuel Pump -  140 GPH Black ® Elect

    Thumbnail Filmstrip of 12-815-1 Holley Black Fuel Pump - 140 GPH Black ® Elect Images

      Purchase 12-815-1 Holley Black Fuel Pump - 140 GPH Black ® Elect

      SKU: HLY-12-815-1
      12-815-1 Holley Black Fuel Pump - 140 GPH Black ® Elect Any fuel ok


      Place your social sharing code here.

      Street/Strip Carbureted Applications Compatible with Gasoline, Alcohol or Methanol

      Good pump to use with our Nitrous kit  to feed the fuel solenoid

      The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70's. Their time proven rotor/vane design is known to get the job done in an affordable package.


      • Tumble polished billet look
      • Lower housing casting designed for enhanced fuel flow
      • Improved design for street/strip applications
      • Distinctive “Black” logo
      • Compatible with alcohol or methanol fuels
      • Not designed for use on aircraft of any type.
      • Flows 140 GPH (free flow)
      • Flows 120 GPH at 9 psi
      • Maximum pressure is 14 psi
      • 3/8” NPT inlet and outlet ports
      • Fuel pressure regulator is required (recommend Holley P/N 12-704 for gasoline & P/N 12-707 for alcohol)
      • Motor draws only 4 amps current
      • Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
      • Provides constant fuel flow with no pulsation
      • Has externally accessible pressure relief valve (max 14 psi)
      • Rotor/vane pump design is more tolerant of contaminated fuels
      • Weighs only 3 lbs
      • Includes mounting bracket
      • Repair kits are readily available
      • Can be serviced from the pump end
      • Use of safety shut-off switch, P/N 12-810, strongly recommended
      • Not designed or recommended for use with fuel injection systems
      • SPECS:
      • Specifications/Information

        Application Universal
        Bracket color Silver
        Brand Holley
        Emission Code 3
        Free Flow GPH 140
        Free Flow LPH 530
        Fuel System Carbureted
        Fuel Type Gasoline / Methanol
        Inlet Size 3/8 inch NPT
        Material Aluminum
        Motor Finish Silver
        Outlet Size 3/8 inch NPT
        Product Type Fuel Pump
        Pump Body color Silver
