IW-302 MoPar BB Balancer 6 Bolt - NOT BLOWER Stock bolt pattern will not align with Stock pulleys
This Big Block Mopar Harmonic Balancer exceeds SFI 18.1 ratings and is designed specifically for High Performance Chryslers.
Stock bolt pattern damper. Due to damper design, will not align with OEM pulleys. Flying magnet conversion will fit passenger side only.
Get rid of your separate Crank Trigger Wheel by integrating it into the Damper itself! - Saves on average about 9 Ounces over the MSD Crank Trigger Wheel.
Bolt on a matching billet aluminum sensor bracket and mounting hardware with passenger (std) mounting.
The double keyway option requires that the factory or aftermarket crankshaft be removed from the engine and a second keyway cut into the snout of the crankshaft. DO NOT run a double keyed damper on a crankshaft without the double keys. Failure to the damper hub can happen without the supporting key in the broached keyway slot. The dual keyway option is for Supercharged or Extreme Duty Applications (typically over 750 rwhp). Without the double key modification your crankshaft in these high horsepower applications can lead to the failure of the damper hub and/or the single keyway which results in damage to the damper and the crankshaft snout.
- Outer Diameter: 7"
- Weight: 8.2 lbs
- Exceeds SFI 18.1 standards and is marked on front with SFI Sticker, and on the rear with SFI number stamped into unit.
