ATM 750 CFM BOOST REFERENCED CARBS EACH- ATM MADE IN USA BY THE FOUNDERS OF QUICK FUEL
Thumbnail Filmstrip of ATM Innovations 750 CFM GAS Boost Referenced Blower Carburetor Images
|
ATM 750CFM Blower GAS Carburetor - Sold Each*
Compares to Quick Fuel but less $$$$$ Made in USA
* Use on 400 + cu in to approx. 500 cu in (depends on boost ) * Use 850 cfm on higher boosted 500-550 cu in engines ATM’s most versatile gas carburetors are its XRB Series that feature a 4150-style flange in sizes from 650cfm all the way up to 1050cfm. It is the perfect blend of a precision die cast aluminum QFT™ carb body with ATM 2-circuit, 5-emulsion billet metering blocks and a billet aluminum throttle body. The idle and high-speed air bleeds and the idle fuel feed and power valve channel restrictions can be changed to tailor a precise fuel curve your application. Incoming fuel is managed by Braswell™ Fuel Chute Lite dual inlet, dual sight-window fuel bowls. They are setup for 7/8”-20 inverted flare fittings that provide a tight, leak-resistant seal. The billet components add durability for frequent calibration changes and strength for the extreme throttle action associated with racing. Gas XRBs come with a silver polished finished and black anodized billet metering blocks and billet throttle bodies. ATM Innovation’s XRB is a step up from its XRC series. While it shares many of the same features with the XRC, the XRB is intended for racers that frequently take apart their carburetors for precise tuning changes – the billet metering blocks add another level of durability over die cast components. The billet throttle bodies are stronger and more precise too. Plus there is more detail work like “slabbed” throttle shafts that promote smoother flow and less turbulence. ATM’s XRB carbs use the QFT™ die cast aluminum carb body that has a fully contoured high-flow air horn and externally changeable idle- and high-speed air bleeds. When combined with ATM’s 2-circuit, 5-emulsion billet metering blocks with 4-corner idle adjustment, the XRB becomes one of the most “tuneable” race carbs on the market. These billet metering blocks also have changeable idle fuel and power valve channel restrictions. Dynamic fuel handling is important in hard-leaving racecars and Braswell’s™ Fuel Chute Lite dual inlet, dual sight-window fuel bowls were designed exactly for this purpose. They are fitted with the 7/8”-20 inverted flare fittings for leak-resistant connections. All XRB Series carbs are available for gas, methanol and E85 fuels. Gas XRBs come with a polished silver finish and black anodized billet metering blocks and billet throttle bodies.
|
ATM INNOVATION: WHO WE ARE
ATM Innovation is a new high-performance company backed by one of the most experienced teams in race carburetor technology. It’s true “that the apple doesn’t fall far from the tree” and CEO Angela Benoit Neely has spent years following in her father’s (Marvin Benoit [founder of Quick Fuel Technology™]) footsteps. She is launching ATM Innovation with years of experience at QFT™ under her belt.
Angela’s mission statement is boldly stated on the banner of this website. It’s the “NEXT Generation In Fuel Systems” which means that ATM is innovating, and re-inventing race carburetors and throttle stops as we now know them. A good example is its new Double D™ throttle stops that not only restrict horsepower when applied, but actually increase horsepower when they are fully open.
