SKU: TBS-LS-192-KIT
ALKYDIGGER TBS Chevy LS TBS 192 Billet 2 Lobe Blower Kit 8MM Drive AD-192-LS THE BLOWER SHOP

AD-192-LS

ALKYDIGGER CHEVY LS TBS 192 MINI BLOWER KIT CATHEDRAL OR RECTANGLE PORT With EFI Port Block Off Plates For Manifold.

(BETTER PHOTOS COMING SOON) Intake missing in first 2 pictures.

LS1 LS2 LS3 LS6 LS7 Engines - 192 Blower Setup - Complete Kit

Fits under hood  usually with no modifications - overall height of manifold, blower and carb adapter is 10.20"

Solid Billet With Billet 2 Lobe Rotors. Mirror Polishing.

Makes PLENTY of boost for any engine from 293ci (4.8L) 325ci (5.3L) 364ci (6.0L). Also 408ci & 427ci. Even up to 454ci (LS7) would recommend a 250 at this point, but 192 would still be fine. -  For Street or Bracket Race Use.

Great Street sleeper blower to hide under the hood.

Also Used in High Compression LS Chevy Race cars to add a maximum of 10-15 lbs (depending on what cubic inch your motor is) of boost to equalize Atmospheric Conditions when the air gets dirty, and/or corrected elevation and density altitude caused a negative impact on your ET .

2 Lobe Straight Rotors w/ Teflon* will make 10-12 LS - even 427 cu in

Specs:

• Billet Cast  -  CNC machined 6061-T6 Aluminum
  • Increased Strength over cast --Hard Anodized Interior --Mirror-Like Polish
  • Low Profile Design (6.56 tall including Billet Carb Adaptor)
  • Single or Dual Carb (4150 or 4500 *Please Specify when Ordering)
• 2 Lobe Rotors
  • Billet  Rotors -Teflon OD Stripping
  • Full length rotor shaft for increased strength
  • Maximum boost at low RPM
• Billet Front Cover
  • Oil Level Sight Glass-Oil Drain Plug-Polished Pressure Relief Valve
• Billet Bearing Plates-Increased Strength over cast
  •

• Included:
  • 192 Billet Supercharger with Long Snout
  • Intake Manifold Cathedral or Rectangle Ports  (4.31 Tall)
  • Accessory Pulley 2V belt or Serpentine
  • Supercharger Pulleys (*Please specify engine size and desired boost when ordering)
  • Belt 8mm 2" wide belt

  • Idler Assembly (Tensioner Bracket with Stands, Pulley & pulley stand, t-nut )
  • All Necessary Gaskets and Hardware
  • (NOT INCLUDED) YOU WILL NEED an Aftermarket Balancer with a 6 bolt Blower or 3 bolt GM patter on it. The balancer MUST BE CORVETTE SPACING. We stock them under our Innovators West  area -  use the Corvette spacing IW-846 for best results.

TBS-192-LS  BLOWER KIT
