    12 Volt Relay  made in usa for protecting the floa

    Thumbnail Filmstrip of 12 Volt Relay made in usa for protecting the floa Images

      Purchase 12 Volt Relay made in usa for protecting the floa

      SKU: Relay-12V-Surge
      12 Volt Relay made in usa for protecting the float in the Surge Tank

      $17.00





      12V   Relay- made in  USA  -  to be used with our surge Tanks

      Warning- do not hook up float to fuel pump without a Relay

      Contact Form : SPDT
      Current Rating : 20 A
      Function : Automotive
      Mounting Type : Panel Mount
      Number of Pins : 5
      Product Header : General Purpose Automotive Power Relay
      Relay Type : Electromechanical
      Termination : QC Tabs
      Voltage, Control : 12 VDC

      https://www.alkydigger.net/TechInfo/wiring-instructions-for-surge-tank-float/



      12 volt positive from key or fuel pump on/off switch will land on terminal 86

      12 volt positive with large enough wire to support fuel pump needs will land on 30.

      87a will run to 12 volt positive on fuel pump itself. Ground of fuel pump can be run to battery or chassis if chassis is grounded.

      Ground will need to be supplied from battery or chassis to level switch in tank. Other lead of level switch will land on terminal 85.

      In many cases you have to connect 30 and  86 together to complete the wiring.



      Overview


      • Wide Temperature Range: -40°C to 125°C

      • Standard ISO Terminal Footprint

      • Handles Heavy Automotive Load; Inrush Current 100 A

      • High Current Path Fully Welded; Reduces Heat Buildup at Full Load

      • Made in North America

      • Coil Ratings: 12 VDC, 74 Ohms

      • Contact Form: SPDT
