    8261  Coil - MSD HVC-II Coil, 7 Series and 8+  MSD  Ignition

    Thumbnail Filmstrip of 8261 Coil - MSD HVC-II Coil, 7 Series and 8+ MSD Ignition Images

      Purchase 8261 Coil - MSD HVC-II Coil, 7 Series and 8+ MSD Ignition

      SKU: MSD-8261
      8261 Coil - MSD HVC-II Coil, 7 Series and 8+ MSD Ignitions

      $334.95





      Molded Coil for 7AL and 8+ MSD
      The ultimate racing coil for your MSD 7 or 8 ignition control!

      The HVC II Coil is completely built in-house so our engineers have exclusive control over their performance and qual­ity. The Coil utilizes an iron U-Core design with a segmented bobbin for improved voltage distribution. The bobbin is molded from Dupont Rynite FR946 material which has incredible dielectric capabilities at high temperatures. MSD also incorporated a cutting edge winding material that has an improved insulation and is also capable of enduring extreme volt­ages. Together, these materials create a durable coil with incredible voltage capabilities, lightning quick rise time and lengthy spark duration. The housing, also molded from Rynite material, features far spaced brass primary terminals and a well protected secondary tower for increased spark isolation. The housing is completely potted with an epoxy compound for vibration resistance and installs with sturdy vibration mounts. For use with MSD 7 and 8 Series Ignitions.

      Features:

      • Designed for racing applications with an MSD 7 or 8 Series Ignition Control
      • New U-core winding design produces more voltage and current
      • 70:1 turns ratio and lower primary resistance produce high voltage output
      • Windings are encased in fracture resistant compound for vibration resistance
      • Dupont Rynite housing with isolated tower and brass primary terminals
      • Supplied with rubber shock mounts





      Brand MSD
      Color Red
      Emission Code 4
      Inductance .250 mH
      Maximum Voltage 45,000 Volts
      Peak Current 2 Amps
      Primary Resistance .016 OHMs
      Product Type Coil
      Secondary Resistance 30 OHMs
      Spark duration 150 uS
      Turns Ratio 70:1
      Type Drag Race / Long Duration Use
      Weight 3.75 lbs.
      Part Number 8261
