Purchase 65 # High Speed Lean Out Valve w -6AN Tee fitting - Suggest 045 055 065 075 pills

SKU: AD-F510-7002-HS
High Speed Lean Out Valve w -6AN Tee fitting - 65 lbs 045 055 065 pill

Name: 65 # High Speed Lean Out Valve w -6AN Tee fitting - Suggest 045 055 065 075 pills
Brand: Alkydigger Fuel Injection-Superchargers-Ignitions
SKU: AD-F510-7002-HS
Price: 134 USD
Availability: InStock

$134.00

Brass or Black Anodized: Brass Valve + $10.00 Black Hard Anodized

Add 4 By Pass Pills --045 055 065 075 +$32.00

Qty

Description

HIGH SPEED -6 LEAN OUT

Hilborn Brass/Black High RPM Lean Out Valve on a 90 degree -6 Tee to install on the barrel valve inlet on many applications, or Rons, or Kinsler Barrel valve

Screw in the top of any -6 Shut Off Valve to Send excessive fuel created by High RPM Back to the tank

Set to 65 lbs Suggest a .045 .055 .065 .075 pill selection Larger will Lean it more

Has -6AN Threads with bulkhead fitting so fuel comes in and by passes - this works well when your pump has only one outlet.

NEW Hilborn Style - Fits Kinsler, Engler, Crower, too (lot less $$ than Kinsler)

This is the valve that you have to install the jets, "pills", in for by passing fuel. Our Pills AD565 AD-565

All mechanical injection systems Reving to over 7000 RPM NEED a HS Lean Out

You can install this Hilborn by pass in your high pressure line or into the pump on any injection. With Enderle, you can relocate

the by pass jet to external if you block off the internal jet.

-6 AN Threads

If you are not sure of your by-pass valve, GET A NEW ONE!
